Rockford Fosgate Monoblock 1000 W Class BD Constant Power Amplifier +Install Kit

• Purchasing this amp and install kit bundle at no additional cost gives you an additional year warranty on your amplifier!
• 24dB/octave crossover
• RCA pass-thru outputs
• Total Power(Sum of Rated Power): 1000 Watts RMS
• Dimensions (H x W x D): 2.14 x 8.14 x 13.66 (in)

Rockford Fosgate Monoblock 1000 W Class BD Constant Power Amplifier +Install Kit



The Power T1000-1bdCP is a 1,000 Watt mono amplifier featuring Constant Power delivering up to 25% more power across all impedance loads. The frequency response of the T1000-1bdCP is optimized exclusively for use with subwoofers.The new Constant Power amplifiers are the most powerful amplifiers on the market PERIOD! The T1000-1bdCP is based on the legendary T1000-1bd amplifier design with a proprietary "Constant Power" configuration delivering up to 25% more power (Watts) across all impedance loads. The listening experience is cleaner, louder and more impressive than ever before. The T1000-1bdCP, pumps out a heart-stopping Kilowatt, enough power for any reasonably sane subwoofer system.



This Listing Includes:

(1) Monoblock 1000 W Class BD Constant Power Amplifier T1000-1bdCP

(1) RFK4 4 Gauge PC-OFC Power Install Amplifier Kit



Features:

- 24dB/octave crossover

- 4 Gauge power/ground connectors

- Audiophile-grade speaker connections

- MOSFET power supply

-MOSFET output stage

- RCA pass-thru outputs

- Infrasonic filter



Specifications:

Number of Channels: 1

Total Power(Sum of Rated Power): 1000 Watts RMS

Bridgeable: No

Frequency Response: 20Hz to 250Hz +/-0.5dB

Input Sensitivity: 150 mV to 4 V

Circuit Topology Class: Class BD

Signal Input: 1 RCA pair

Signal Output: 1 RCA pair

Tone Controls: Bass: 0dB to +18dB @ 45Hz

Power Wire Gauge: 4 AWG

Power Input Connector: Block

Speaker Wire Gauge: 8 AWG to 18 AWG

Speaker Output Connector: Block

Cooling: Convection

Operating Voltage: 9 - 16 VDC

Recommended Fuse(not included): 150 A

Average Current Draw (13.8V Music): 70 A

Max. Current Draw (13.8V Sinewave): 140 A

Suggested Alternator: 100 A



Rated Power(RMS Continuous Power):

- 700 Watts x 1 @ 4-Ohm

- 1000 Watts x 1 @ 2-Ohm

- 1000 Watts x 1 @ 1-Ohm



Dynamic Power(PVC/PowerCube):

- 772 Watts x 1 @ 4-Ohms

- 1299 Watts x 1 @ 2-Ohms

- 1395 Watts x 1 @ 1-Ohm



Efficiency (average):

- 85.6% @ 4-Ohm

- 82.1% @ 2-Ohm

- 70% @ 1-Ohm



Total Harmonic Distortion (THD+Noise):

- 4-Ohm: Less than 1.0%

- 2-Ohm: Less than 1.0%

- 1-Ohm: Less than1.0%



Crossover Controls:

- Low-Pass (LP): 35Hz-250Hz @ 24dB/octave Butterworth

- Infrasonic: 12dB/octave Butterworth, -3dB @ 28Hz



Visual Indicators:

- Power (Blue LED)

- Thermal (Red LED)

- Protect (Yellow LED)



Dimensions (H x W x D):

- 2.14 x 8.14 x 13.66 (in)
