Massive Combo 7 Band Graphic Equalizer EQ7X + 3 Way Electronic Crossover TRI-XO
The Massive EQ 7X is a half din 7 Band Graphic EQ that will correct peaks and dips in sound characteristics associated with most vehicles' interior that dampens and limits both speaker output and imaging. This EQ provides powerful features in a compact size.
The TRI-XO is a flexible easy to use a 3-way electronic crossover with subwoofer control. The TRI-XO has been designed with infinitely adjustable asymmetrical electronic crossovers using frequency multipliers that can multiply frequency crossover points at a slope rate of 18dB per octave using a 3rd order Butterworth design. With the infinitely selectable crossover points, system settings become an art of precision. There are three sets of RCA inputs and three sets of 5V outputs with a selectable 180? Phase switch. Engaging the parallel input feature can reduce the number of RCA source outputs while the supplied under dash remote bass gain can boost output @ 50Hz up to 18dB
This Listing Includes:
(1) Equalizer EQ7X
(1) Crossover TRI-XO
(1) Bass Knob
- 3-Way Electronic Crossover with Sub Control
- Infinitely Adjustable Asymmetrical Crossovers
- 14.4 Volts DC negative ground power source
- 0.5 Amp Max Input Current
- 0.01% THD @ 1V Output Level
- 10Hz - 30KHz - 3dB
- 60dB Separation
- 10dB Per Octave 3rd Order Butterworth X-Over
- 20K Ohm Input Impedance
- 100 Ohm Output Impedance
- 1:2 (+6dB) Output Gain
- Dims ~5.98" x 7.08" x 1.69"
- 5V Max Output Voltage Level 180? Phase Switch
- Under Dash Remote Included 50Hz up to 12dB
Power Source: 14.4V DC Negative Ground
Input Current: 0.5 amp Max
Distortion: 0.01% THD at 1V Output Level
Frequency Response: 10Hz-30kHz +/- 3dB
S/N Ratio: Less than 100dB
Channel Separation: 60dB
Crossover Slope Rate: 18dB per Octave 3rd Order Butterworth
Input Impedance: 20K Ohms
Output Impedance: 100 Ohms
Output Gain: 1:2 (+6dB)
Output Voltage Level: 5V Max
5.98" x 7.08" x 1.69"
- 1/2 DIN
- 7 Band Graphic Equalizer
- Gold Plated RCA Connectors
- 50Hz, 125Hz, 320Hz, 750Hz, 2.2KHz, 6KHz, 16KHz
- Each Frequency Adjustable From -12dB to +12dB
- * -15dB to +15dB for Subwoofer Frequencies
- Subwoofer Output Built-In 18dB per Octave electronic X-Over fixed @ 60Hz or 120Hz
- 8 Volt Output Line Driver
- RCA Auxiliary Input (Rear) inputs for MP3, DVD, or Phone
- 6-Channel / 7 Volt RCA Outputs (Front/Rear/Subwoofer)
- Separate Controls for Master, Sub, Volume (Sublevel) Front / Rear, Fader, Main, or AUX Inputs
- Extended Frequency Response from 20HZ ~ 30Hz / 100dB S/N
- Adjustable Master Volume Level Control
- Adjustable Active Gain Preamp
- 30V Bi-Polar Switching Power Supply
- 20dB Headroom
- Adjustable Subwoofer Level Control
- Input Impedance 20K Ohms
- Output Impedance 2K Ohms
- Stereo Separation 82dB / 1KHz
- Operating Voltage 11V - 15V Negative Ground
- ISO Mounting Holes / Removable Trim Ring
- 2-Channel RCA Input with Adjustable Gain
7"(W) " 1"(H) " 4 1/8"(D)
