Massive Audio Nano Edge 4 Channel Amplifier 4800 Watt Full Range Class D EX4R

Massive Audio SKU: MA-EX4R


Shipping calculated at checkout

Only 1 left!

Massive Audio Nano Edge 4 Channel Amplifier 4800 Watt Full Range Class D EX4R

Versatility is the name of the game with our EX4R "NANO EDGE" Series Amplifier. The EX4R is a Full Range, Multi-Channel, Class AB Amplifier capable of up to 1200 Watts X 4 RMS depending on system configuration. Even at 4 Ohms, it will deliver a powerful 800 Watts RMS to each of 4 channels. Crack open the compact case and you'll find this EX4R uses our "Nano Block", Mil-Spec, Double-Sided PCB with Surface Mount Devices. Further inspection reveals our tried & true "N" drive MOSFET power supplies that ensure high performance for either casual listening or competition grade Sound Quality systems. We have left nothing to chance, this EX4R features our most advanced next-generation 5-way protection circuitry and a Differential input switch to eliminate noise.

This Listing Includes:
(1) 4 Channel Amplifier EX4R

- Built-In OEM Line Converter
- Clip Light Indicator
- Differential Input Switch to Eliminate Noise
- 1,200 Watts x 4 RMS Power
- X1 / X10 Crossover Switching
- High Power in Extremely Small Heat Sink
- Mil-Spec Double Sided PCB with SMD Parts
- Built-in Noise Reduction Circuitry
- Full Mosfet with High-Grade Switching Devices
- Versatile Full Range Class D Technology
- CTA-2006 Compliant
- Built-in Auto Sensing Turn-on via Hi-Input
- 12v Remote Output for External Devices
- 0~12dB Variable Bass Boost
- Next-Gen Advanced 5 Way Protection

RMS Power @ 4 Ohm: 800w x 4
RMS Power @ 2 Ohm: 1,200w x 4
PEAK Power: 1,600w x 4
Bridged RMS : 2,400w x 2 @ 4 Ohm
Min Impedance: 2 Ohm Stereo
Min Ohm Bridged: 4 Ohm
THD: More Than 0.1% @ 4 Ohm
S/N: Less Than 90 dB
Input Level: 0.4~10V (Hi Inputs or Low Inputs)
Freq. Response: 20Hz ~ 30KHz
LPF: 20Hz ~ 250Hz / 200Hz ~ 2.5KHz
Subsonic Filter : 20Hz ~ 300Hz / 200Hz ~ 3KHz
External Fuse: 200A

Dimensions: 14.09 (in) x 5.9 (in) x 2.1 (in)
