Massive Audio Monoblock 4000W Amplifier Full Range Digital Compact E4F

Massive Audio SKU: MA-E4F


Shipping calculated at checkout

Only 8 left!

Massive Audio Monoblock 4000W Amplifier Full Range Digital Compact E4F

Don't let its diminutive size fool you, this ultra-compact Massive Audio E4F "EDGE" Series Amplifier is a Class D powerhouse capable of up to 2000 Watts RMS at 1 Ohm. With a frequency range of 25Hz - 18KHz, this amplifier will deliver high current for Subwoofers, Mid-Range, and Full Range Speakers!

Its Class D design enables its compact footprint and cool running within all system configurations. There's no need to worry about "running out of gas", our E4F has a regulated power supply and dual output voltage.

This Listing Includes:
(1) 4000W Amplifier E4F

- Built-In OEM Line Converter
- Versatile Full Range 25Hz - 18KHz Class D Monoblock
- High Power in Extremely Small Heat Sink
- Differential Input Switch to Eliminate Noise
- Clip LED to Indicate Signal Clipping
- Mil Spec Double Sided PCB with SMD Parts
- Built-in Noise Reduction Circuitry
- Full Mosfet with High-Grade Switching Devices
- Regulated Power Supply & Dual Output Voltage
- CTA-2006 Compliant
- Built-in Auto Sensing Turn-on via Hi-Input
- 12v Remote Output for External Devices
- 0~12dB Variable Bass Boost
- Next Gen Advanced 5 Way Protection

RMS Power @ 1 Ohm: 2000w x 1
PEAK Power: 4000w x 1
RMS @ 2 Ohms: 1400w x 1
Bridged RMS: n/a
Min Impedance: 1 Ohm
Min Ohm Bridged: n/a
THD: Less Than 0.1% @ 4 Ohm
S/N: More Than 95 dB
Max Voltage: 15v
Max RCA Voltage: 10v
Freq. Response: 25Hz - 18KHz

Dimensions: 8.58 (in) x 5.9 (in) x 2.1 (in)
