DS18 10" Woofer Dual 2 ohm 1600 Watt Max Power Car Subwoofer ZXI10.2D
More Power, More Bass!
Designed to provide thumping power that shakes everyones mirrors, the ZXI10.2D is a newly designed subwoofer that could only be defined as a monster of a machine. It packs a 2.5-inch voice coil thats made to withstand high amounts of power with unparalleled efficiency while producing thunderous bass thats free from distortion. Dont get it twisted, this sub is versatile enough to play higher frequencies under 900Hz down to 20Hz with incredible clarity and accuracy!
This listing includes:
(1) DS18 10 Subwoofer ZXI10.2D
SPECIFICATIONS PER SUBWOOFER:
Nominal Diameter: 10" / 254mm
Nominal Impedance:2 + 2 ohms
MAX Power Handling: 1600w
RMS Power Handling: 800w
Sensitivity (1w/1m):86dB
Frequency Response: 20Hz-900Hz
Recommended Lo Pass Crossover: 90Hz
MOTOR:
Voice Coil Diameter: 2.5" / 63.5mm
Voice Coil Former Material: Black Aluminum
Winding Material: CCAW
Cone Material: Non-Pressed Paper
Dust Cap Material: PPI
Surround Material: Foam
Basket Material: Aluminum
Basket Color: Sandblasted Black
Magnet Material: Ferrite
Magnet Weight: 196 Oz (4 x 49 oz)
Displacement Volume: 2.23L / 0.078ft3
THIELE & SMALL PARAMETERS:
Equivalent Volume: Vas - 18.25L / 0.644ft3
Excursion: X-max - 28.5mm
Free Air Resonance: Fs - 29Hz
Mechanical Factor: Qms - 6.825
Electrical Factor: Qes - 0.493
Total Factor: Qts - 0.457
DC Resistance: Re - 2.0+2.0 ohms
Moving Mass: Mms - 265.089g
Compliance: Cms - .0.142mm/N
Force Factor: BL - 25.146
Voice Coil Inductance: Le -51.23 mH
Diaphragm Area: Sd - 330.06cm
Efficiency Bandwidth Product: EBP - 58.8
RECOMMENDED ENCLOSURES:
Sealing Internal Volume: 14.2L / 0.5ft3
Sealed Box Output Response: F3 - 41.5Hz
Ported Internal Volume: 35.4L / 1.25ft3
Port Size (WxHxL): 1.16"x10.31x24.49" / 29.5 x 262 x 622.1mm
Port Tunning Frequency: Fb - 30Hz
Ported Box Output Response: F3 -24Hz
DIMENSIONS PER SPEAKER:
Overall Diameter: 10.96" / 278.5mm
Front Mount Baffle Cutout: 9.36" / 237.7mm
Mounting Depth: 6.91" / 175.5mm
Overall Depth: 8.34" / 212mm
Motor Diameter: 6.69" / 170mm
