DS18 Car Audio 8" Midrange Loudspeaker /w Bullet 4 Ohm 550 Watt PRO-X8.4BM

DS18 SKU: DS-PRO-X8.4BM

$58.95

Shipping calculated at checkout

Available Now!

DS18 Car Audio 8" Midrange Loudspeaker /w Bullet 4 Ohm 550 Watt PRO-X8.4BM

With strong midrange and clear high frequencies, these loudspeakers deliver a concert-like audio experience without any distortion. Even better, the 1.5” 4-ohms voice coil handles high heat temperatures without breaking a sweat so you can blast your favorite music on a regular basis for extended periods of time. The high 96 dB sensitivity of the PRO-X8.4BM lets you crank up the volume without any sound distortion, while the 125Hz to 16KHz frequency provides richer and more accurate tones that any audiophile will immediately notice. These loudspeakers can also handle up to 275 Watts RMS, making it capable of handling consistent and heavy usage. Put this baby on max volume and enjoy extreme volume levels with crystal clarity!

This listing includes:
(1) DS18 8“ Midrange Loudspeaker PRO-X8.4BM

SPECIFICATIONS PER SPEAKER:
Nominal Diameter: 8“ (203.2mm)
Nominal Impedance: 4 Ohms
MAX Power Handling: 550 Watts
RMS Power Handling: 275 Watts
Sensitivity (1w/1m): 96dB
Frequency Response: 125Hz ~ 16KHz
Recommended HI Pass Crossover: 120Hz

MOTOR:
Voice Coil Diameter: 1.5“ (38.1mm)
Voice Coil Former Material: Kapton
Winding Material: CCAW
Basket Material: Steel
Magnet Material: Ferrite
Magnet Weight: 30 oz

THIELE & SMALL PARAMETERS:
Equivalent Volume: Vas - 26.60L
Excursion: X-max - 9.3mm
Free Air Resonance: Fs - 93Hz
Mechanical Factor: Qms - 9.275
Electrical Factor: Qes - 0.589
Total Factor: Qts - 0.552
DC Resistance: Re - 3.2 Ohms

DIMENSIONS PER SPEAKER:
Overall Diameter: 8.22“ (209mm)
Front Mount Baffle Cutout: 7.17“ (182mm)
Mounting Depth: 3.11“ (79mm)
Overall Depth: 3.39“ (86mm)
Motor Diameter: 4.72“ (120mm)
