DD Audio 10" Dual 2 Ohm 3000W Peak/1000W RMS Hi-Def Tuned Subwoofer 610f-D2

SKU DD-610F-D2
Save 20% Save 20%
Original price $411.99
Original price $411.99 - Original price $411.99
Original price $411.99
Current price $329.00
$329.00 - $329.00
Current price $329.00
Snap Logo Lease for as low as $/week Learn More

Free Gifts when added to Cart

The more you spend, the greater selection of free gifts you'll have at your fingertips when selecting items in your shopping cart!

Spend More, Save More

Big Jeff loves his customers!!!
  • Spend $250, Save 3%
  • Spend $500, Save 5%
  • Spend $1000, Save 10%
  • Spend $1500, Save 11%
  • Spend $2500, Save 12%
  • Spend $5000, Save 15%

*Does not apply to: Sundown, XS power & Kicker products*

*Does not stack with other promotional sales*

This is a Sample Product Title
Was $200.00 Now $100.00
  • Superior Power Handling: 1000W RMS and 3000W peak performance
  • Advanced Thermal Management: Vented aluminum components for efficient heat dissipation
  • Enhanced Excursion: 22mm Xmax for deeper bass
  • Robust Build: Durable design with double-stitched cone and polished aluminum accents
  • Versatile Enclosure Compatibility: Suitable for 1.25 to 1.75 CuFt ported enclosures

DD Audio 10" Dual 4 Ohm 3000W Peak/1000W RMS Hi-Def Tuned Subwoofer 610f-D2

This Listing Includes:

(1) DD Audio 610F 10 Inch Power Tuned Subwoofer

The DD Audio 610f-D2 is a 10-inch, high-definition, power-tuned subwoofer with impressive specifications. It delivers 1000 Watts RMS and peaks at 3000 Watts, with a dual 2 Ohm impedance. The subwoofer boasts a 2.5-inch voice coil diameter, an 8.5-inch piston diameter, and a frequency response starting at 34 Hz. Key parameters include Qms of 5.047, Qes of 0.454, Qts of 0.416, and a Vas of 33.91 liters. Its mechanical excursion (Xmech) is 60mm, with a maximum linear excursion (Xmax) of 22mm. The frame's outer diameter is 10.625 inches (10.75 inches with gasket), a mounting diameter of 9.39 inches, and a mounting depth of 7.25 inches. The motor has a diameter of 7 inches and a depth of 3.375 inches. It requires a woofer displacement of 0.08 cubic feet and works best in a ported enclosure ranging from 1.25 to 1.75 cubic feet. Priced at $329 each, this subwoofer features enhanced thermal cooling, a double-stitched fiberglass-loaded cone, a polished aluminum design with DD logos, and a rubber boot wrapped motor. It is designed for powerful performance with an increased Xmax and a high-temperature 2.5-inch voice coil.


  • Speaker Size (In): 10

  • Watts RMS: 1000

  • Watts Peak: 3000

  • Impedance: D2

  • VCD (In): 2.5

  • Piston Diameter (In): 8.5

  • Fs (Hz): 34

  • Qms: 5.047

  • Qes: 0.454

  • Qts: 0.416

  • Vas (Liters): 33.91

  • Xmech (MM): 60

  • Xmax (MM): 22

  • Frame OD (In): 10.625

  • Frame OD w/Gasket (In): 10.75

  • Mounting Diameter (In): 9.39

  • Mounting Depth (In): 7.25

  • Motor Diameter (In): 7

  • Motor Depth (In): 3.375

  • Woofer Displacement (CuFt): 0.08

  • Ported Enclosure (CuFt): 1.25 - 1.75


  • Enhanced thermal cooling with vented aluminum voice coil insert and heatsink

  • Double-stitched fiberglass loaded, non-pressed cone

  • Elegant design with polished aluminum DD logos and rubber boot wrapped motor

  • Increased Xmax for powerful performance

  • High-temp 2.5-inch voice coil for superior power handling
