Audio Ace Diamond X8 8" 180W RMS 4 Ohm Pro Car Audio Coaxial Speaker Pair

• 180W RMS EACH: Pair of 8" pro audio coaxial speakers delivering 360 watts RMS combined power handling for powerful aftermarket car audio systems.
• COAXIAL DESIGN: Integrated high-frequency drivers deliver strong vocal projection and clear treble from a single speaker assembly.
• 98 dB SENSITIVITY: High-efficiency speakers with an 80 Hz–20 kHz frequency response for powerful midrange and high-frequency reproduction.
• HEAVY-DUTY CONSTRUCTION: Features a 1.52" voice coil, 34.3 oz manufacturer-listed motor, and custom-tooled Audio Ace basket.
• BLACK OR WHITE OPTIONS: Includes two 4-ohm speakers in your selected color, ideal for custom door panels, speaker pods, and high-output audio installations.

Audio Ace Diamond X8 8" 180W RMS 4 Ohm Pro Car Audio Coaxial Speaker Pair

This Listing Includes:

• (2) Audio Ace Diamond X8 8" Coaxial Speakers in your selected color (Black or White)

Bring powerful vocals and crisp high-frequency detail to your car audio system with the Audio Ace Diamond X8. These high-efficiency 8" pro audio coaxial speakers deliver 180 watts RMS each, providing 360 watts RMS combined power handling per pair for demanding audio installations.

The Diamond X8 combines PA-style midrange performance with an integrated high-frequency driver, giving you strong vocal projection and treble reproduction from a single speaker assembly. Each speaker features a 1.52" voice coil, 34.3 oz motor structure, and 98 dB sensitivity to deliver efficient, high-output sound. Its wide 80 Hz to 20 kHz frequency response makes it an excellent choice for systems that need both powerful mids and clear highs.

Built with a custom-tooled basket featuring the Audio Ace logo, the Diamond X8 is designed for custom door panels, speaker pods, loud daily drivers, and demo vehicles. Available in Black or White to match your custom audio setup.

Features:

• 180W RMS Power Handling Per Speaker


• 360W RMS Combined Power Handling Per Pair


• 360W Maximum Power Handling Per Speaker


• 8" Pro Audio Coaxial Speaker Design


• 4-Ohm Impedance Per Speaker


• Integrated High-Frequency Driver


• 1.52" Voice Coil


• 34.3 oz Motor Structure


• 98 dB Sensitivity


• 80 Hz–20 kHz Frequency Response


• Custom-Tooled Basket with Audio Ace Logo


• Available in Black or White


• Sold as a Pair

Specifications:

• Brand: Audio Ace


• Series: Diamond


• Model: Diamond X8


• Speaker Size: 8"


• Speaker Type: Pro Audio Coaxial


• RMS Power Handling: 180W Each


• Maximum Power Handling: 360W Each


• Combined RMS Power Handling: 360W Per Pair


• Impedance: 4 Ohms Each


• Voice Coil Diameter: 1.52" (38.6 mm)


• Magnet Weight: 34.3 oz (33 oz on Manufacturer Spec Sheet)


• Magnet Diameter: 120 mm


• Magnet Height: 20 mm


• Sensitivity: 98 dB


• Frequency Response: 80 Hz–20 kHz


• Resonant Frequency (Fs): 88 Hz


• Qes: 0.373


• Qms: 5.848


• Qts: 0.351


• Diaphragm Area (Sd): 213.82 cm²


• DC Resistance (Re): 4 Ohms


• Force Factor (BL): 8.323 Tm


• Xmax: 1.75 mm


• Color Options: Black, White


• Quantity: 2 Speakers

Dimensions:

• Overall Diameter: 8.25"


• Mounting Depth: 3.625"

Application: High-output car audio systems, custom door panels, speaker pods, speaker walls, coaxial speaker upgrades, loud daily drivers, and demo vehicles.
