8" 200W RMS 4-Ohm SVC Subwoofer Kicker CompC Series / 50CWCS84

8" 200W RMS 4-Ohm SVC Subwoofer Kicker CompC Series / 50CWCS84

This Listing Includes:

• (1) 50CWCS84 Subwoofer

Description:

The 8" 200W RMS 4-Ohm SVC Subwoofer Kicker CompC Series is the perfect addition to any car audio system, delivering powerful bass and superb sound quality. This subwoofer is engineered with high-performance materials to ensure deep, impactful lows that enhance your music experience. The Kicker CompC Series is renowned for its durability and reliability, making it a trusted choice for audio enthusiasts. Its compact design allows for easy installation in a wide range of vehicles, providing versatility and convenience. With the Kicker CompC Series, you can enjoy an immersive audio experience that transforms your driving pleasure.

Download Owner's Manual

Features:

• Single Four-Ohm Voice Coil and Reengineered for Increased Excursion and Deeper Bass
• Injection-Molded Polypropylene Cone
• Forced-Air Cooling™ for Outstanding Durability
• Ribbed Polyurethane Surround
• Signature Yellow Surround Stitching
• High-Strength Spiralead™ Tinsel Leads
• Stamped Steel Basket
• High Temp Voice Coil
• Spring-Loaded Speaker Terminals

Specifications:

• Size [in, cm]: 8, 20
• Recommended Amplifier Power [watts RMS]: 100-200
• Peak Power Handling [watts, per ANSI/CTA-2031-A]: 400
• Sensitivity [dB 1w/1m]: 83.3
• Rated Impedance [OHMS]: 4 SVC
• Frequency Response [Hz]: 30-500
• Fs [Hz]: 42.2

Thiele & Small Parameters:

Electrical Parameters

• Re: 3.94 | Ohm | electrical voice coil resistance at DC
• Krm: 0.00225 | Ohm | WRIGHT inductance mode
• Erm: 0.92 | WRIGHT inductance mode
• Kxm: 0.01595 | Ohm | WRIGHT inductance mode
• Exm: 0.79 | WRIGHT inductance mode
• Cmes: 738.915 | µF | electrical capacitance representing moving mass
• Lces: 18.73 | mH | electrical inductance representing driver compliance
• Res: 51.855 | Ohm | resistance due to mechanical losses
• fs: 42.8 | Hz | driver resonance frequency

Mechanical Parameters

• Mms: 59.433 | g | mechanical mass of driver diaphragm assembly including air load and voice coil
• Mmd(Sd): 56.2115 | g | mechanical mass of voice coil and diaphragm without air load
• Rms: 1.5535 | kg/s | mechanical resistance of total-driver losses
• Cms: 0.233 | mm/N | mechanical compliance of driver suspension
• Kms: 4.295 | N/mm | mechanical stiffness of driver suspension
• Bl: 8.9685 | Tm | force factor (Bl product)

Loss Parameters

• Qtp: 0.7935 | total Q-factor considering all losses
• Qms: 10.2985 | mechanical Q-factor of driver in free air considering Rms only
• Qes: 0.783 | electrical Q-factor of driver in free air considering Re only
• Qts: 0.7275 | total Q-factor considering Re and Rms only

Other Parameters

• Vas: 13.3223 | I | equivalent air volume of suspension
• n0: 0.128 | reference efficiency (2 pi-radiation using Re)
• Lm: 83.275 | dB | characteristic sound pressure level (SPL at 1m for 1W @ Re)
• Lnom: 83.34| dB | nominal sensitivity (SPL at 1m for 1W @ Zn)
• Sd: 201.06 | sq cm | diaphragm area
• Xmax: 11.125 | mm

Measurements:

• Outer Frame Dimension [in, cm]: 8-9/16, 21.7
• Mounting Depth [in, cm]: 4-3/16, 10.5
• Mounting Cutout [in, cm]: 6-15/16, 17.7

Enclosure Suggestions:

• Max Rec Sealed Box Vol [cu. ft, liters]: 1.2, 34
• Min Rec Sealed Box Vol [cu. ft, liters]: 0.5, 14.2
• Max Rec Vented Box Vol [cu. ft, liters]: 1.2, 34
• Min Rec Vented Box Vol [cu. ft, liters]: 0.66, 18.7
