2MP Starlight Dome Motorized WDR HDCVI IR Security Camera HCC5V221R-IR-Z-P

2MP Starlight Dome Motorized WDR HDCVI IR Security Camera HCC5V221R-IR-Z-P

Experience 1080P full HD video and the simplicity of reusing existing coaxial infrastructure with HDCVI. The Starlight HDCVI camera with 120db true WDR presents a high-quality image with rich details even in extreme low-light conditions. This model is a PoC camera which can be powered by PoC XVR or PoC transmitter over a single coaxial cable with video, requiring no separate power supplies. PoC reduces installation time and costs, making it an ideal choice for applications with complex deployment but a tight budget.

This listing includes:
(1) Camera
(1) Manual
(1) Installation Hardware

Specifications:
Camera
Image Sensor: 1/2.8" CMOS
Effective Pixels 1937(H)x1097(V), 2.1MP
Scanning System: Profressive
Electronic Shutter Speed: PAL: 1/4s-1/100000s / NTSC: 1/3-1/100000s
Minimum Illuminations: 0.005Lux/F1.3, 30IRE, OLux IR on
S/N Ratio: More than 65dB
IR Distance: Up to 30m (98 feet)
IR On/Off Control: Auto/Manual
IR LEDs: 2
Lens:
Lens type: Motorized lens/fixed iris
Mount type: Board-in
Focal Lenght: 2.7-13.5mm
Max Aperture: F1.3
Angle of View: H:102-29
Focus Control: Auto/Manual
Close Focus Distance: 200mm/ 7.87"
DORI Distance:
*Note: The DORI distance is a "general proximity" of distance which makes easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test results according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.
Dori Distance
Detect 25px/m 47m (153ft) 153m (502ft)
Observe 63px/m 19m (153ft) 612m(201ft)
Recognize 125px/m 9m (31 ft) 31m(100ft)
Identify 250px/m 5m/ (15 ft) 15m (50ft)
Pan/Tilt/Rotation
Pan/Tilt/Rotation Pan: 0 - 355 Tilt: 0 - 75 Rotation: 0-355
Video
Resolution: 1080P (1920x1080)
Frame Rate: 25/30fps@1080P, 25/30fps@720P
Video Output: 1-channels BNC high definition video output/ CVBS Video Output (can switch)
Day/Night: Auto (ICR)/ Manual
OSD Menu: Multi-Language
BLC Mode: BLC/HLC
WDR: 120dB
Gain Control: AGC
Noise Reduction: 2D/3D
White Balance: Auto/Manual
Smart IR: Auto/Manual
Certifications: CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC PART 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No 60950-1)
INTERFACE
Audio Interface: N/A
Electrical
Power Supply : POC/12V DC25%
Power Cunsumption: Max 8.8w (12V DC, IR on)
Power Output: 12V DC, Max.2W
Environmental:
Operating Conditions: -40C - + 60C {-40F - +140F)/ Less than 90% RH *Start up should be done at above -40C (-40F)
Storage Conditions: -40C - + 60C {-40F - +140F)/ Less than 90% RH
Ingress Protection & Vandal Resistance: IP67 & IK10
Construction:
Casing: Aluminum
Dimensions 122mmx88.9mm (4.8"x3.5")
Net Weight: .48kg (1.06lb)
Gross Weight: .63kg (1.39lb)
