DS18 Car Audio 10" Mid Range Loud Speaker 660 Watt 4 Ohm PRO-GM10.4

DS18 SKU: DS-PRO-GM10.4

$49.95

Shipping calculated at checkout

Available Now!

DS18 Car Audio 10" Mid Range Loud Speaker 660 Watt 4 Ohm PRO-GM10.4

Everyone's favorite is now available in 4-Ohms During the focused R&D period of perfecting the PRO-EXL line, DS18 identified the opportunity to spawn off another line since there was a division amongst competition audiophiles and concert/"voceteo" audiophiles. Therefore, DS18 created the PRO-GM audio line, which features a wide variety of midranges the produce concert-like sounds that will knock the wind out of you.

A midrange driver is called upon to handle the most significant part of the audible sound spectrum, the region where the most fundamentals emitted by musical instruments and, most importantly, the human voice, lie. This region contains sounds which are the most familiar to the human ear, and where discrepancies from faithful reproduction are most easily observed. It is therefore paramount that a mid-range driver of good quality be capable of low-distortion reproduction.

This listing includes:
(1) DS18 10" Loudspeaker PRO-GM10.4

SPECIFICATIONS:
Nominal Diameter: 10" (254mm)
Nominal Impedance: 4 Ohms
RMS Power Handling: 220 Watts
Max Power Handling: 660 Watts
Sensitivity: 95 dB
Frequency Response: 40Hz ~ 6.3kHz
Recommended Hi Pass Crossover: 90Hz
Voice Coil Diameter: 2" (50.8mm)
Voice Coil Former Material: Kapton
Winding Material: CCAW
Cone Material: Paper
Dust-cap Material: Paper
Surround Material: Cloth
Basket Material: Steel
Basket Color: Matte Black
Magnet Material: Ferrite
Magnet Weight: 30 Oz

THIELE & SMALL PARAMETERS:
Equivalent Volume: Vas - 79.3L / 2.8ft³
Free Air Resonance: Fs - 59Hz
Mechanical Factor: Qms - 14.565
Electrical Factor: Qes - 0.808
Total Factor: Qts - 0.765
Mechanical Mass: Mms - 15.6g
Mechanical Compliance: Cms - 0.462mm/N
BL Factor: BL - 4.98
Voice Coil Inductance: Le - 0.599mH
Cone Area: Sd - 349.67cm²
DC Resistance: Re - 3.4 Ohms

MEASUREMENTS:
Overall Diameter: 10.1" (256mm)
Overall Depth: 4.06 (103mm)
Front Mount Baffle Count: 9.05" (230mm)
Mounting Depth: 3.7" (96mm)
Motor Diameter: 4.72" (120mm)
