- 200W RMS POWER: DS18 PRO-NS8.4 8" midrange loudspeaker handles 200 watts RMS and 400 watts maximum power with 4-ohm impedance for high-output car audio systems.
- ULTRA-SLIM NEODYMIUM MAGNET: Compact 3.32 oz neodymium motor design allows a shallow 2.48" mounting depth, ideal for installations with limited space.
- 96DB SENSITIVITY: High-efficiency midrange speaker with a 97Hz to 12kHz frequency response, designed for strong vocals and detailed midrange reproduction.
- 2-INCH COPPER VOICE COIL: Features a KSV voice coil former, paper cone, cloth surround, and steel basket with a glossy black finish.
- SHALLOW MOUNT DESIGN: Features an 8.2" overall diameter, 7.12" mounting cutout, and 2.48" mounting depth. DS18 recommends a 160Hz high-pass crossover. Sold individually.
DS18 PRO 8" Mid-Range Speaker 400 Watt 4 Ohm With Ultra Slim Neodymium Magnet
This Listing Includes:
- (1) DS18 8" Mid-Range Speaker PRO-NS8.4
Big Midrange Sound. Shallow Mounting. No Compromises on Space.
Need serious midrange output but don't have room for a bulky speaker? The DS18 PRO-NS8.4 8" Midrange Loudspeaker brings powerful performance to tight installations with its ultra-slim neodymium magnet and shallow mounting design.
Handling 200 watts RMS and 400 watts max power, this 4-ohm speaker is built to deliver strong vocals, detailed instrumentation, and impressive midrange presence. Its 96dB sensitivity helps produce high output efficiently, making it a great option for custom door panels and high-performance car audio systems.
The compact neodymium motor allows for a mounting depth of just 2.48 inches, giving you more installation flexibility without sacrificing speaker size. A 2" copper voice coil, paper cone, and cloth surround work together to deliver responsive midrange performance, while the glossy black steel basket provides a clean, durable foundation.
With a frequency response of 97Hz to 12kHz and a manufacturer-recommended 160Hz high-pass crossover, the PRO-NS8.4 is designed to handle the midrange frequencies your system needs while leaving the deep bass to your subwoofers.
Whether you're upgrading your daily driver or building custom speaker panels, the DS18 PRO-NS8.4 delivers the output you want in a space-saving design.
Features
- Ultra-slim neodymium magnet allows for shallow mounting
- High Power handling of 400 Watts for high-volume listening
- Glossy Black Basket finish
Specifications:
- Nominal Diameter: 8"
- Nominal Impedance: 4 ohms
- RMS Power Handling: 200W
- MAX Power Handling: 400W
- Sensitivity (1w/1m): 96dB
- Frequency Response: 97Hz-12KHz
- Recommended Hi-Pass Crossover: 160Hz
- Voice Coil Diameter: 2" / 50.8mm
- Voice Coil Former Material: KSV
- Winding Material: Copper
- Cone Material: Paper
- Dust Cap Material: Paper
- Surround Material: Cloth
- Basket Material: Steel
- Magnet Material: Neodymium
- Magnet Weight: 3.32 oz / 94.12g
THIELE & SMALL PARAMETERS
- Equivalent Volume: 4.8L
- Excursion (one way): 2 mm
- Free Air Resonance: 117Hz
- Mechanical Factor: 4.643
- Electrical Factor: 1.147
- Total Factor: .92
- Mechanical Mass: 12.294 g
- Mechanical Compliance: 157m cm/N
- BL Factor: 4.8
- Voice Coil Inductance: 2.532 mH
- Cone Area: 213.825 cm3
- DC Resistance: 3.2 ohms
- Mechanical Mass w/o air: 12.294g
Dimensions:
- Overall Diameter: 8.2" / 208 mm
- Overall Depth: 2.67" / 68 mm
- Front Mount Baffle Cutout: 7.12"/181 mm
- Mounting Depth: 2.48" / 63 mm
- Motor Diameter: 4.33" / 110 mm
